Computer Vision with Python and PyTorch: Part 3 - Semantic Segmentation

import torch
import torch.nn as nn
import torch.nn.functional as F
import torchvision
import torchvision.transforms as transforms
from torchvision import datasets
import matplotlib.pyplot as plt
import numpy as np
from PIL import Image
import cv2

def visualize_segmentation(image, mask, classes, alpha=0.7):
    """
    Visualize segmentation mask overlaid on original image
    """
    # Create color map for classes
    colors = plt.cm.Set3(np.linspace(0, 1, len(classes)))

    # Convert mask to RGB
    h, w = mask.shape
    mask_rgb = np.zeros((h, w, 3))

    for class_id, color in enumerate(colors):
        mask_rgb[mask == class_id] = color[:3]

    # Overlay on original image
    if isinstance(image, torch.Tensor):
        image = image.permute(1, 2, 0).numpy()

    # Normalize image if needed
    if image.max() <= 1.0:
        image = (image * 255).astype(np.uint8)

    # Blend images
    blended = cv2.addWeighted(
        image.astype(np.uint8),
        1 - alpha,
        (mask_rgb * 255).astype(np.uint8),
        alpha,
        0
    )

    plt.figure(figsize=(15, 5))

    plt.subplot(1, 3, 1)
    plt.imshow(image)
    plt.title('Original Image')
    plt.axis('off')

    plt.subplot(1, 3, 2)
    plt.imshow(mask_rgb)
    plt.title('Segmentation Mask')
    plt.axis('off')

    plt.subplot(1, 3, 3)
    plt.imshow(blended)
    plt.title('Overlay')
    plt.axis('off')

    plt.tight_layout()
    plt.show()

# Example usage
# visualize_segmentation(image, mask, ['background', 'person', 'car', 'road'])

from torch.utils.data import Dataset, DataLoader
import os
import json

class CityscapesDataset(Dataset):
    """
    Custom dataset class for Cityscapes-style segmentation data
    """
    def __init__(self, root_dir, split='train', transforms=None):
        self.root_dir = root_dir
        self.split = split
        self.transforms = transforms

        # Define class mapping
        self.classes = [
            'background', 'road', 'sidewalk', 'building', 'wall', 'fence',
            'pole', 'traffic_light', 'traffic_sign', 'vegetation', 'terrain',
            'sky', 'person', 'rider', 'car', 'truck', 'bus', 'train',
            'motorcycle', 'bicycle'
        ]

        self.class_to_idx = {cls: idx for idx, cls in enumerate(self.classes)}
        self.num_classes = len(self.classes)

        # Load image and mask file paths
        self.images_dir = os.path.join(root_dir, 'images', split)
        self.masks_dir = os.path.join(root_dir, 'masks', split)

        self.image_files = sorted([f for f in os.listdir(self.images_dir)
                                  if f.endswith(('.jpg', '.png'))])

    def __len__(self):
        return len(self.image_files)

    def __getitem__(self, idx):
        # Load image
        img_name = self.image_files[idx]
        img_path = os.path.join(self.images_dir, img_name)
        image = Image.open(img_path).convert('RGB')

        # Load mask
        mask_name = img_name.replace('.jpg', '.png')  # Assuming masks are PNG
        mask_path = os.path.join(self.masks_dir, mask_name)
        mask = Image.open(mask_path)
        mask = np.array(mask, dtype=np.int64)

        if self.transforms:
            image, mask = self.transforms(image, mask)

        return image, mask

class SegmentationTransforms:
    """
    Custom transforms for segmentation that apply same transforms to both image and mask
    """
    def __init__(self, image_size=(256, 256), train=True):
        self.image_size = image_size
        self.train = train

    def __call__(self, image, mask):
        # Resize
        image = image.resize(self.image_size, Image.BILINEAR)
        mask = Image.fromarray(mask).resize(self.image_size, Image.NEAREST)
        mask = np.array(mask, dtype=np.int64)

        if self.train:
            # Random horizontal flip
            if np.random.rand() > 0.5:
                image = image.transpose(Image.FLIP_LEFT_RIGHT)
                mask = np.fliplr(mask)

            # Random crop (simplified)
            # Add more augmentations as needed

        # Convert to tensor
        image = transforms.ToTensor()(image)
        image = transforms.Normalize(
            mean=[0.485, 0.456, 0.406],
            std=[0.229, 0.224, 0.225]
        )(image)

        mask = torch.from_numpy(mask).long()

        return image, mask

# Create datasets
# train_dataset = CityscapesDataset(
#     root_dir='path/to/cityscapes',
#     split='train',
#     transforms=SegmentationTransforms(train=True)
# )

# val_dataset = CityscapesDataset(
#     root_dir='path/to/cityscapes',
#     split='val',
#     transforms=SegmentationTransforms(train=False)
# )

# Data loaders
# train_loader = DataLoader(train_dataset, batch_size=8, shuffle=True, num_workers=4)
# val_loader = DataLoader(val_dataset, batch_size=8, shuffle=False, num_workers=4)

class FCN(nn.Module):
    """
    Fully Convolutional Network for semantic segmentation
    """
    def __init__(self, num_classes=21, pretrained=True):
        super(FCN, self).__init__()

        # Use pre-trained VGG16 as backbone
        vgg = torchvision.models.vgg16(pretrained=pretrained)

        # Extract features (all layers except classifier)
        self.features = vgg.features

        # Convert classifier to fully convolutional
        self.classifier = nn.Sequential(
            nn.Conv2d(512, 4096, kernel_size=7),
            nn.ReLU(inplace=True),
            nn.Dropout2d(0.5),
            nn.Conv2d(4096, 4096, kernel_size=1),
            nn.ReLU(inplace=True),
            nn.Dropout2d(0.5),
            nn.Conv2d(4096, num_classes, kernel_size=1)
        )

        # Transposed convolution for upsampling
        self.upsample = nn.ConvTranspose2d(
            num_classes, num_classes, kernel_size=64, stride=32, padding=16
        )

    def forward(self, x):
        input_size = x.size()[2:]

        # Feature extraction
        x = self.features(x)

        # Classification
        x = self.classifier(x)

        # Upsample to original size
        x = self.upsample(x)

        # Crop to exact input size
        x = x[:, :, :input_size[0], :input_size[1]]

        return x

fcn_model = FCN(num_classes=20)
print(f"FCN parameters: {sum(p.numel() for p in fcn_model.parameters()):,}")

class DoubleConv(nn.Module):
    """Double convolution block used in U-Net"""
    def __init__(self, in_channels, out_channels, mid_channels=None):
        super().__init__()
        if not mid_channels:
            mid_channels = out_channels
        self.double_conv = nn.Sequential(
            nn.Conv2d(in_channels, mid_channels, kernel_size=3, padding=1, bias=False),
            nn.BatchNorm2d(mid_channels),
            nn.ReLU(inplace=True),
            nn.Conv2d(mid_channels, out_channels, kernel_size=3, padding=1, bias=False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU(inplace=True)
        )

    def forward(self, x):
        return self.double_conv(x)

class Down(nn.Module):
    """Downscaling with maxpool then double conv"""
    def __init__(self, in_channels, out_channels):
        super().__init__()
        self.maxpool_conv = nn.Sequential(
            nn.MaxPool2d(2),
            DoubleConv(in_channels, out_channels)
        )

    def forward(self, x):
        return self.maxpool_conv(x)

class Up(nn.Module):
    """Upscaling then double conv"""
    def __init__(self, in_channels, out_channels, bilinear=True):
        super().__init__()

        if bilinear:
            self.up = nn.Upsample(scale_factor=2, mode='bilinear', align_corners=True)
            self.conv = DoubleConv(in_channels, out_channels, in_channels // 2)
        else:
            self.up = nn.ConvTranspose2d(in_channels, in_channels // 2, kernel_size=2, stride=2)
            self.conv = DoubleConv(in_channels, out_channels)

    def forward(self, x1, x2):
        x1 = self.up(x1)

        # Pad x1 to match x2 size if needed
        diffY = x2.size()[2] - x1.size()[2]
        diffX = x2.size()[3] - x1.size()[3]
        x1 = F.pad(x1, [diffX // 2, diffX - diffX // 2,
                        diffY // 2, diffY - diffY // 2])

        # Concatenate along channel dimension
        x = torch.cat([x2, x1], dim=1)
        return self.conv(x)

class UNet(nn.Module):
    """
    U-Net architecture for semantic segmentation
    """
    def __init__(self, n_channels=3, n_classes=21, bilinear=False):
        super(UNet, self).__init__()
        self.n_channels = n_channels
        self.n_classes = n_classes
        self.bilinear = bilinear

        self.inc = DoubleConv(n_channels, 64)
        self.down1 = Down(64, 128)
        self.down2 = Down(128, 256)
        self.down3 = Down(256, 512)
        factor = 2 if bilinear else 1
        self.down4 = Down(512, 1024 // factor)

        self.up1 = Up(1024, 512 // factor, bilinear)
        self.up2 = Up(512, 256 // factor, bilinear)
        self.up3 = Up(256, 128 // factor, bilinear)
        self.up4 = Up(128, 64, bilinear)
        self.outc = nn.Conv2d(64, n_classes, kernel_size=1)

    def forward(self, x):
        x1 = self.inc(x)
        x2 = self.down1(x1)
        x3 = self.down2(x2)
        x4 = self.down3(x3)
        x5 = self.down4(x4)

        x = self.up1(x5, x4)
        x = self.up2(x, x3)
        x = self.up3(x, x2)
        x = self.up4(x, x1)
        logits = self.outc(x)

        return logits

unet_model = UNet(n_channels=3, n_classes=20, bilinear=False)
print(f"U-Net parameters: {sum(p.numel() for p in unet_model.parameters()):,}")

class ASPPConv(nn.Sequential):
    def __init__(self, in_channels, out_channels, dilation):
        modules = [
            nn.Conv2d(in_channels, out_channels, 3, padding=dilation, dilation=dilation, bias=False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU()
        ]
        super(ASPPConv, self).__init__(*modules)

class ASPPPooling(nn.Sequential):
    def __init__(self, in_channels, out_channels):
        super(ASPPPooling, self).__init__(
            nn.AdaptiveAvgPool2d(1),
            nn.Conv2d(in_channels, out_channels, 1, bias=False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU())

    def forward(self, x):
        size = x.shape[-2:]
        for mod in self:
            x = mod(x)
        return F.interpolate(x, size=size, mode='bilinear', align_corners=False)

class ASPP(nn.Module):
    """
    Atrous Spatial Pyramid Pooling module
    """
    def __init__(self, in_channels, atrous_rates, out_channels=256):
        super(ASPP, self).__init__()
        modules = []
        modules.append(nn.Sequential(
            nn.Conv2d(in_channels, out_channels, 1, bias=False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU()))

        rates = tuple(atrous_rates)
        for rate in rates:
            modules.append(ASPPConv(in_channels, out_channels, rate))

        modules.append(ASPPPooling(in_channels, out_channels))

        self.convs = nn.ModuleList(modules)

        self.project = nn.Sequential(
            nn.Conv2d(len(self.convs) * out_channels, out_channels, 1, bias=False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU(),
            nn.Dropout(0.5))

    def forward(self, x):
        res = []
        for conv in self.convs:
            res.append(conv(x))
        res = torch.cat(res, dim=1)
        return self.project(res)

class DeepLabV3(nn.Module):
    """
    DeepLabV3 with ResNet backbone
    """
    def __init__(self, num_classes=21, output_stride=16):
        super(DeepLabV3, self).__init__()

        # Use ResNet50 as backbone
        resnet = torchvision.models.resnet50(pretrained=True)

        # Modify ResNet for segmentation
        self.backbone = nn.Sequential(*list(resnet.children())[:-2])

        # ASPP module
        if output_stride == 16:
            atrous_rates = [6, 12, 18]
        else:  # output_stride == 8
            atrous_rates = [12, 24, 36]

        self.aspp = ASPP(2048, atrous_rates)

        # Final classifier
        self.classifier = nn.Sequential(
            nn.Conv2d(256, 256, 3, padding=1, bias=False),
            nn.BatchNorm2d(256),
            nn.ReLU(),
            nn.Dropout(0.1),
            nn.Conv2d(256, num_classes, 1)
        )

    def forward(self, x):
        input_size = x.shape[-2:]

        # Feature extraction
        features = self.backbone(x)

        # ASPP
        x = self.aspp(features)

        # Classification
        x = self.classifier(x)

        # Upsample to input size
        x = F.interpolate(x, size=input_size, mode='bilinear', align_corners=False)

        return x

deeplab_model = DeepLabV3(num_classes=20)
print(f"DeepLab parameters: {sum(p.numel() for p in deeplab_model.parameters()):,}")

class SegmentationLoss(nn.Module):
    """
    Combined loss function for semantic segmentation
    """
    def __init__(self, num_classes, ignore_index=255, weight=None):
        super(SegmentationLoss, self).__init__()
        self.num_classes = num_classes
        self.ignore_index = ignore_index

        # Cross entropy loss
        self.ce_loss = nn.CrossEntropyLoss(weight=weight, ignore_index=ignore_index)

        # Dice loss for better boundary handling
        self.dice_loss = DiceLoss(num_classes, ignore_index)

    def forward(self, predictions, targets):
        ce_loss = self.ce_loss(predictions, targets)
        dice_loss = self.dice_loss(predictions, targets)

        # Combine losses
        total_loss = ce_loss + dice_loss

        return total_loss, ce_loss, dice_loss

class DiceLoss(nn.Module):
    """
    Dice loss for segmentation
    """
    def __init__(self, num_classes, ignore_index=255, smooth=1e-5):
        super(DiceLoss, self).__init__()
        self.num_classes = num_classes
        self.ignore_index = ignore_index
        self.smooth = smooth

    def forward(self, predictions, targets):
        # Convert predictions to probabilities
        probs = F.softmax(predictions, dim=1)

        # Create one-hot encoding for targets
        targets_one_hot = F.one_hot(targets, self.num_classes).permute(0, 3, 1, 2).float()

        # Mask out ignore_index
        if self.ignore_index is not None:
            mask = (targets != self.ignore_index).unsqueeze(1).float()
            probs = probs * mask
            targets_one_hot = targets_one_hot * mask

        # Calculate Dice coefficient for each class
        dice_scores = []
        for class_idx in range(self.num_classes):
            pred_class = probs[:, class_idx]
            target_class = targets_one_hot[:, class_idx]

            intersection = torch.sum(pred_class * target_class)
            union = torch.sum(pred_class) + torch.sum(target_class)

            dice = (2.0 * intersection + self.smooth) / (union + self.smooth)
            dice_scores.append(dice)

        # Average Dice loss
        dice_loss = 1.0 - torch.mean(torch.stack(dice_scores))

        return dice_loss

class FocalLoss(nn.Module):
    """
    Focal loss for handling class imbalance
    """
    def __init__(self, alpha=1, gamma=2, reduction='mean', ignore_index=255):
        super(FocalLoss, self).__init__()
        self.alpha = alpha
        self.gamma = gamma
        self.reduction = reduction
        self.ignore_index = ignore_index

    def forward(self, inputs, targets):
        ce_loss = F.cross_entropy(inputs, targets, reduction='none', ignore_index=self.ignore_index)
        pt = torch.exp(-ce_loss)
        focal_loss = self.alpha * (1-pt)**self.gamma * ce_loss

        if self.reduction == 'mean':
            return focal_loss.mean()
        elif self.reduction == 'sum':
            return focal_loss.sum()
        else:
            return focal_loss

def train_segmentation_model(model, train_loader, val_loader, num_epochs=50):
    device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')
    model.to(device)

    # Loss function and optimizer
    criterion = SegmentationLoss(num_classes=20)
    optimizer = torch.optim.Adam(model.parameters(), lr=1e-4, weight_decay=1e-5)
    scheduler = torch.optim.lr_scheduler.ReduceLROnPlateau(
        optimizer, mode='min', factor=0.5, patience=5, verbose=True
    )

    best_val_loss = float('inf')
    train_losses = []
    val_losses = []

    for epoch in range(num_epochs):
        print(f'Epoch {epoch+1}/{num_epochs}')
        print('-' * 20)

        # Training phase
        model.train()
        running_loss = 0.0
        running_ce_loss = 0.0
        running_dice_loss = 0.0

        for i, (images, masks) in enumerate(train_loader):
            images = images.to(device)
            masks = masks.to(device)

            optimizer.zero_grad()

            # Forward pass
            outputs = model(images)
            total_loss, ce_loss, dice_loss = criterion(outputs, masks)

            # Backward pass
            total_loss.backward()
            optimizer.step()

            running_loss += total_loss.item()
            running_ce_loss += ce_loss.item()
            running_dice_loss += dice_loss.item()

            if (i + 1) % 10 == 0:
                print(f'Batch [{i+1}/{len(train_loader)}], '
                      f'Loss: {total_loss.item():.4f}')

        # Calculate epoch losses
        epoch_loss = running_loss / len(train_loader)
        epoch_ce_loss = running_ce_loss / len(train_loader)
        epoch_dice_loss = running_dice_loss / len(train_loader)

        train_losses.append(epoch_loss)

        # Validation phase
        val_loss = validate_segmentation_model(model, val_loader, criterion, device)
        val_losses.append(val_loss)

        print(f'Train Loss: {epoch_loss:.4f} (CE: {epoch_ce_loss:.4f}, Dice: {epoch_dice_loss:.4f})')
        print(f'Val Loss: {val_loss:.4f}')

        # Save best model
        if val_loss < best_val_loss:
            best_val_loss = val_loss
            torch.save(model.state_dict(), 'best_segmentation_model.pth')
            print('Saved best model!')

        scheduler.step(val_loss)
        print()

    return train_losses, val_losses

def validate_segmentation_model(model, val_loader, criterion, device):
    model.eval()
    running_loss = 0.0

    with torch.no_grad():
        for images, masks in val_loader:
            images = images.to(device)
            masks = masks.to(device)

            outputs = model(images)
            total_loss, _, _ = criterion(outputs, masks)

            running_loss += total_loss.item()

    return running_loss / len(val_loader)

# Train the model
# train_losses, val_losses = train_segmentation_model(unet_model, train_loader, val_loader)

def calculate_iou(pred, target, num_classes, ignore_index=255):
    """
    Calculate Intersection over Union (IoU) for each class
    """
    ious = []
    pred = pred.flatten()
    target = target.flatten()

    # Remove ignored pixels
    if ignore_index is not None:
        mask = target != ignore_index
        pred = pred[mask]
        target = target[mask]

    for class_id in range(num_classes):
        pred_inds = pred == class_id
        target_inds = target == class_id

        if target_inds.sum() == 0:  # No ground truth for this class
            ious.append(float('nan'))
            continue

        intersection = (pred_inds & target_inds).sum().float()
        union = (pred_inds | target_inds).sum().float()

        if union == 0:
            ious.append(float('nan'))
        else:
            ious.append((intersection / union).item())

    return ious

def evaluate_segmentation(model, test_loader, num_classes, device, class_names=None):
    """
    Comprehensive evaluation of segmentation model
    """
    model.eval()
    all_ious = []
    pixel_acc_total = 0
    pixel_count_total = 0

    with torch.no_grad():
        for images, masks in test_loader:
            images = images.to(device)
            masks = masks.to(device)

            # Forward pass
            outputs = model(images)
            predictions = torch.argmax(outputs, dim=1)

            # Calculate metrics for each image in batch
            for pred, target in zip(predictions.cpu(), masks.cpu()):
                # IoU calculation
                ious = calculate_iou(pred, target, num_classes)
                all_ious.append(ious)

                # Pixel accuracy
                correct_pixels = (pred == target).sum().float()
                total_pixels = target.numel()

                pixel_acc_total += correct_pixels
                pixel_count_total += total_pixels

    # Calculate mean IoU
    all_ious = np.array(all_ious)
    mean_ious = np.nanmean(all_ious, axis=0)
    overall_miou = np.nanmean(mean_ious)

    # Calculate pixel accuracy
    pixel_accuracy = (pixel_acc_total / pixel_count_total).item()

    # Print results
    print(f'Overall mIoU: {overall_miou:.4f}')
    print(f'Pixel Accuracy: {pixel_accuracy:.4f}')
    print('\nPer-class IoU:')

    for i, iou in enumerate(mean_ious):
        class_name = class_names[i] if class_names else f'Class {i}'
        print(f'{class_name}: {iou:.4f}')

    return overall_miou, pixel_accuracy, mean_ious

# Example evaluation
# miou, pixel_acc, class_ious = evaluate_segmentation(
#     unet_model, test_loader, num_classes=20, device=device, class_names=dataset.classes
# )

import seaborn as sns
from sklearn.metrics import confusion_matrix

def plot_segmentation_confusion_matrix(model, test_loader, class_names, device, normalize=True):
    """
    Plot confusion matrix for segmentation results
    """
    model.eval()
    all_preds = []
    all_targets = []

    with torch.no_grad():
        for images, masks in test_loader:
            images = images.to(device)
            masks = masks.cpu().numpy()

            outputs = model(images)
            predictions = torch.argmax(outputs, dim=1).cpu().numpy()

            # Flatten predictions and targets
            for pred, target in zip(predictions, masks):
                # Remove ignore pixels
                mask = target != 255
                all_preds.extend(pred[mask])
                all_targets.extend(target[mask])

    # Calculate confusion matrix
    cm = confusion_matrix(all_targets, all_preds, labels=range(len(class_names)))

    if normalize:
        cm = cm.astype('float') / cm.sum(axis=1)[:, np.newaxis]

    # Plot
    plt.figure(figsize=(12, 10))
    sns.heatmap(cm, annot=True, fmt='.2f' if normalize else 'd',
                xticklabels=class_names, yticklabels=class_names,
                cmap='Blues')
    plt.title('Segmentation Confusion Matrix')
    plt.ylabel('True Label')
    plt.xlabel('Predicted Label')
    plt.tight_layout()
    plt.show()

    return cm

# Example usage
# cm = plot_segmentation_confusion_matrix(unet_model, test_loader, dataset.classes, device)

class MultiScaleTraining:
    """
    Multi-scale training for better segmentation performance
    """
    def __init__(self, base_size=512, scales=[0.5, 0.75, 1.0, 1.25, 1.5]):
        self.base_size = base_size
        self.scales = scales

    def __call__(self, image, mask):
        # Randomly select a scale
        scale = np.random.choice(self.scales)
        new_size = int(self.base_size * scale)

        # Resize image and mask
        image = image.resize((new_size, new_size), Image.BILINEAR)
        mask = Image.fromarray(mask).resize((new_size, new_size), Image.NEAREST)
        mask = np.array(mask)

        # Random crop to base_size if larger
        if new_size > self.base_size:
            h, w = mask.shape
            start_h = np.random.randint(0, h - self.base_size + 1)
            start_w = np.random.randint(0, w - self.base_size + 1)

            image = image.crop((start_w, start_h,
                              start_w + self.base_size,
                              start_h + self.base_size))
            mask = mask[start_h:start_h + self.base_size,
                       start_w:start_w + self.base_size]

        # Pad if smaller
        elif new_size < self.base_size:
            pad = self.base_size - new_size
            pad_top = pad // 2
            pad_bottom = pad - pad_top

            image = np.array(image)
            image = np.pad(image, ((pad_top, pad_bottom), (pad_top, pad_bottom), (0, 0)),
                          mode='constant')
            image = Image.fromarray(image)

            mask = np.pad(mask, ((pad_top, pad_bottom), (pad_top, pad_bottom)),
                         mode='constant', constant_values=255)

        return image, mask

def test_time_augmentation(model, image, device, scales=[0.75, 1.0, 1.25]):
    """
    Test-time augmentation for better inference results
    """
    model.eval()
    predictions = []

    with torch.no_grad():
        for scale in scales:
            # Scale image
            h, w = image.shape[-2:]
            new_h, new_w = int(h * scale), int(w * scale)

            scaled_image = F.interpolate(
                image.unsqueeze(0),
                size=(new_h, new_w),
                mode='bilinear',
                align_corners=False
            )

            # Forward pass
            output = model(scaled_image.to(device))

            # Scale back to original size
            output = F.interpolate(
                output,
                size=(h, w),
                mode='bilinear',
                align_corners=False
            )

            predictions.append(output)

            # Also test horizontal flip
            flipped_image = torch.flip(scaled_image, dims=[3])
            flipped_output = model(flipped_image.to(device))
            flipped_output = torch.flip(flipped_output, dims=[3])
            flipped_output = F.interpolate(
                flipped_output,
                size=(h, w),
                mode='bilinear',
                align_corners=False
            )
            predictions.append(flipped_output)

    # Average all predictions
    final_prediction = torch.mean(torch.stack(predictions), dim=0)
    return final_prediction

# Example usage
# multiscale_transform = MultiScaleTraining(base_size=256, scales=[0.5, 0.75, 1.0, 1.25])
# tta_prediction = test_time_augmentation(model, test_image, device)

class MedicalSegmentationModel(nn.Module):
    """
    Specialized U-Net for medical image segmentation
    """
    def __init__(self, in_channels=1, out_channels=2):  # Grayscale input, binary output
        super(MedicalSegmentationModel, self).__init__()
        self.unet = UNet(n_channels=in_channels, n_classes=out_channels)

    def forward(self, x):
        return self.unet(x)

def preprocess_medical_image(image_path, target_size=(256, 256)):
    """
    Preprocess medical images (DICOM, etc.)
    """
    # For DICOM files, you would use pydicom
    # import pydicom
    # dicom = pydicom.dcmread(image_path)
    # image = dicom.pixel_array

    # For now, assume regular image files
    image = Image.open(image_path).convert('L')  # Grayscale
    image = image.resize(target_size)

    # Normalize to [0, 1]
    image = np.array(image, dtype=np.float32) / 255.0

    # Apply medical-specific normalization
    # (e.g., HU windowing for CT scans)

    return transforms.ToTensor()(image)

def calculate_dice_coefficient(pred, target):
    """
    Calculate Dice coefficient for medical segmentation
    """
    smooth = 1e-5
    pred_flat = pred.flatten()
    target_flat = target.flatten()

    intersection = (pred_flat * target_flat).sum()
    union = pred_flat.sum() + target_flat.sum()

    dice = (2.0 * intersection + smooth) / (union + smooth)
    return dice

class AutonomousDrivingSegmentation:
    """
    Real-time segmentation for autonomous driving
    """
    def __init__(self, model_path, device):
        self.device = device
        self.model = self.load_model(model_path)

        # Cityscapes classes relevant for driving
        self.driving_classes = {
            0: 'road',
            1: 'sidewalk',
            2: 'building',
            3: 'wall',
            4: 'fence',
            5: 'pole',
            6: 'traffic_light',
            7: 'traffic_sign',
            8: 'vegetation',
            9: 'terrain',
            10: 'sky',
            11: 'person',
            12: 'rider',
            13: 'car',
            14: 'truck',
            15: 'bus',
            16: 'train',
            17: 'motorcycle',
            18: 'bicycle'
        }

        # Define colors for visualization
        self.colors = np.random.randint(0, 255, (len(self.driving_classes), 3))

    def load_model(self, model_path):
        model = DeepLabV3(num_classes=19)
        model.load_state_dict(torch.load(model_path, map_location=self.device))
        model.to(self.device)
        model.eval()
        return model

    def preprocess_frame(self, frame):
        """Preprocess video frame for segmentation"""
        # Resize and normalize
        frame_rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
        frame_pil = Image.fromarray(frame_rgb)

        transform = transforms.Compose([
            transforms.Resize((256, 512)),  # Typical driving camera aspect ratio
            transforms.ToTensor(),
            transforms.Normalize(mean=[0.485, 0.456, 0.406],
                               std=[0.229, 0.224, 0.225])
        ])

        return transform(frame_pil).unsqueeze(0)

    def segment_frame(self, frame):
        """Segment a single frame"""
        with torch.no_grad():
            input_tensor = self.preprocess_frame(frame).to(self.device)
            output = self.model(input_tensor)
            prediction = torch.argmax(output, dim=1).squeeze().cpu().numpy()

        return prediction

    def visualize_segmentation(self, frame, segmentation):
        """Overlay segmentation on original frame"""
        # Resize segmentation to match frame size
        h, w = frame.shape[:2]
        segmentation_resized = cv2.resize(segmentation.astype(np.uint8), (w, h),
                                        interpolation=cv2.INTER_NEAREST)

        # Create colored segmentation
        colored_seg = np.zeros((h, w, 3), dtype=np.uint8)
        for class_id in range(len(self.driving_classes)):
            mask = segmentation_resized == class_id
            colored_seg[mask] = self.colors[class_id]

        # Blend with original frame
        alpha = 0.6
        blended = cv2.addWeighted(frame, 1-alpha, colored_seg, alpha, 0)

        return blended

    def process_video(self, video_path, output_path):
        """Process entire video for segmentation"""
        cap = cv2.VideoCapture(video_path)

        # Get video properties
        fps = cap.get(cv2.CAP_PROP_FPS)
        width = int(cap.get(cv2.CAP_PROP_FRAME_WIDTH))
        height = int(cap.get(cv2.CAP_PROP_FRAME_HEIGHT))

        # Setup video writer
        fourcc = cv2.VideoWriter_fourcc(*'mp4v')
        out = cv2.VideoWriter(output_path, fourcc, fps, (width, height))

        while True:
            ret, frame = cap.read()
            if not ret:
                break

            # Segment frame
            segmentation = self.segment_frame(frame)

            # Visualize
            result_frame = self.visualize_segmentation(frame, segmentation)

            # Write frame
            out.write(result_frame)

        cap.release()
        out.release()

# Example usage
# driving_segmenter = AutonomousDrivingSegmentation('cityscapes_model.pth', device)
# driving_segmenter.process_video('driving_video.mp4', 'segmented_output.mp4')

def optimize_model_for_deployment(model, example_input):
    """
    Optimize segmentation model for deployment
    """
    model.eval()

    # 1. TorchScript compilation
    traced_model = torch.jit.trace(model, example_input)

    # 2. Quantization (for CPU deployment)
    quantized_model = torch.quantization.quantize_dynamic(
        model, {nn.Conv2d, nn.Linear}, dtype=torch.qint8
    )

    # 3. ONNX export (for cross-platform deployment)
    torch.onnx.export(
        model,
        example_input,
        "segmentation_model.onnx",
        export_params=True,
        opset_version=11,
        input_names=['input'],
        output_names=['output'],
        dynamic_axes={'input': {0: 'batch_size'}, 'output': {0: 'batch_size'}}
    )

    return traced_model, quantized_model

# Benchmark different optimizations
def benchmark_models(original_model, traced_model, quantized_model, test_input, device):
    """
    Compare inference speed of different model optimizations
    """
    import time

    models = {
        'Original': original_model,
        'TorchScript': traced_model,
        'Quantized': quantized_model
    }

    results = {}

    for name, model in models.items():
        model.eval()

        # Warmup
        for _ in range(10):
            with torch.no_grad():
                _ = model(test_input)

        # Benchmark
        times = []
        for _ in range(100):
            start_time = time.time()
            with torch.no_grad():
                _ = model(test_input)
            end_time = time.time()
            times.append(end_time - start_time)

        avg_time = np.mean(times) * 1000  # Convert to milliseconds
        results[name] = avg_time

        print(f'{name}: {avg_time:.2f} ms per inference')

    return results

# Example usage
# example_input = torch.randn(1, 3, 256, 256).to(device)
# traced_model, quantized_model = optimize_model_for_deployment(unet_model, example_input)
# benchmark_results = benchmark_models(unet_model, traced_model, quantized_model, example_input, device)
